MicroDyn Motor
1 / 4
Motor Customized Specification, Please contact me.
The length of shaft can be customized, Please contact me.
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m / gf.cm) | Power (W) | Current (A) | Torque (mN.m / gf.cm) | ||
| RS-770H | 8523R | 6.0~12.0 | 12 VDC | 15000 | 2.2 | 13177 | 15.91 | 81 / 826.2 | 111.8 | 115 | 666.9 / 6802 |
| RS-775H | 25110R | 6.0~24.0 | 24 VDC | 3478 | 0.15 | 2925 | 0.75 | 44.4 / 452.9 | 13.35 | 4.07 | 245.7 / 2506 |
We're factory. We specialize in micro DC motors and DC gear motors for more than 14 years.
We can draw up an Ali Assurance Order Online for our new customer, which can pay online with Master Card, Visa, etc. Customers can also pay with PayPal, TT, etc.
Yes, we can customize a suitable motor according to our customer's specific technical requirements.
Yes, we have CE, FCC, ISO, etc. If you have other certification requirements, we can apply for them for you.
We have professional checking staff on every production line process. After finishing the whole motor, we have dedicated testing machines including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise Testers to verify complete quality compliance.
Yes, the length of the shaft and other motor specifications can be fully customized according to your application requests.
