390 Dc Motor for Machine Fan From Shenzhen Supplier 12v 6000rpm Motor

Send Inquiry

Product Description

Product Description

390 dc motor for machine fan 12v 6000rpm motor

Product Details

Motor Customized Specification, Please contact me.

Reference Drawing

------ RS - 365

------ RS - 385

------ RS - 395

The length of shaft can be customized, Please contact me.

Reference Datasheet

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	A	RPM	A	mN.m / gf.cm	W	A	mN.m / gf.cm
RS-390SH	20156R	6.0~12.0	12VDC	5000	0.08	4243	0.33	6.07 / 61.9	2.72	2.22	42.2 / 430
RS-390SH	2975	6.0~12.0	12VDC	12000	0.29	10165	0.33	5.75 / 58.6	1.31	8.9	80.4 / 820
RS-395SH	15130	6.0~12.0	12VDC	3650	0.66	2949	0.25	5.83 / 59.5	1.8	1.06	30.4 / 310
RS-395SH	15100R	6.0~24.0	24VDC	10300	0.07	8893	0.38	7.09 / 72.3	6.68	2.66	54.9 / 560

Frequently Asked Questions (FAQ)

What are the available voltage ranges for these PMDC motors?

The RS-390 and RS-395 motors operate within voltage ranges of 6.0V to 12.0V DC or 6.0V to 24.0V DC depending on the specific model.

Can the motor shaft length and specifications be customized?

Yes, both the shaft length and overall motor specifications can be fully customized to meet your machine requirements.

What is the rated speed of the RS-390SH (2975 model) at 12VDC?

The RS-390SH (2975 model) features a no-load speed of 12,000 RPM and a rated speed of 10,165 RPM under load at 12VDC.

Which motor models are featured in the reference drawings?

Reference drawings are provided for the RS-365, RS-385, and RS-395 micro DC motor models.

What is the difference in stall torque between the RS-390SH and RS-395SH?

The stall torque ranges from 42.2 mN.m (430 gf.cm) to 80.4 mN.m (820 gf.cm) for the RS-390SH, and from 30.4 mN.m (310 gf.cm) to 54.9 mN.m (560 gf.cm) for the RS-395SH depending on model type.

Are these motors suitable for machine fan applications?

Yes, these high-speed 12V and 24V PMDC motors are optimized for machine fans, cooling fans, and other industrial micro-rotation equipment.
