MicroDyn Motor
1 / 4
| Parameter | Specification Details |
|---|---|
| Ratio | 241k |
| Max. Rated Torque | 1.5~2.0 Kgf.cm |
| Max. Gear Breaked Torque | 4~5 Kgf.cm |
| Gearbox Efficiency | 45%~60% |
| Gearmotor Model | Ratio | Rated Voltage (V) | No-Load | Rated | Stall | ||||
|---|---|---|---|---|---|---|---|---|---|
| Speed | Current | Speed | Current | Torque | Current | Torque | |||
| RPM | mA | RPM | mA | N.m / Kgf.cm | mA | N.m / Kgf.cm | |||
| GM2215FMN20-241K | 1 : 241 | 4.5 VDC | 43 | ≤ 50 | 34 | ≤ 120 | 25 / 250 | ≤ 350 | 0.15 / 1.5 |
| 58 | ≤ 65 | 50 | ≤ 130 | 28 / 280 | ≤ 680 | 0.18 / 1.8 | |||
| 68 | 75 | 56 | ≤ 140 | 30 / 300 | ≤ 750 | 0.2 / 2.0 | |||
| PMDC MOTOR Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||
|---|---|---|---|---|---|---|---|---|---|
| Speed | Current | Speed | Current | Torque | Current | Torque | |||
| RPM | mA | RPM | mA | mN.m / gf.cm | mA | mN.m / gf.cm | |||
| SL-N20 | 04510500 | 4.5 VDC | 10500 | ≤ 30 | 8250 | ≤ 80 | 0.2 / 2.0 | ≤ 300 | 1.05 / 10.5 |
| 04514000 | 4.5 VDC | 14000 | ≤ 40 | 12000 | ≤ 130 | 0.25 / 2.5 | ≤ 680 | 1.5 / 15 | |
| 04516500 | 4.5 VDC | 16500 | ≤ 50 | 13500 | ≤ 160 | 0.25 / 2.5 | ≤ 750 | 1.8 / 18 | |
We are a factory specializing in producing motors for more than 14 years. Our professional R&D team and mature management system ensure a premium cooperation experience.
To guarantee reliability, we carefully inspect every step of the process—from incoming raw materials to final shipping. Continuous quality control is the foundation of our development.
A: We are a factory. We have specialized in micro DC motors and DC gear motors for more than 14 years.
A: We can draft an Alibaba Trade Assurance Order online for new customers, which allows payment via MasterCard, Visa, etc. Customers can also choose to pay via PayPal, TT, or other convenient methods.
A: Yes, we can design and customize a suitable motor according to our customers' specific requirements.
A: Yes, we have CE, FCC, ISO, and other relevant certifications. If you have additional certification requirements, we can apply for them accordingly.
A: We employ professional inspection staff at every stage of the production line. Once the motor assembly is completed, we run comprehensive diagnostics using specialized equipment such as Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise Testers.
